GIGABYTE B760 DS3H DDR4, motherboard
€ 159.00 excl.VAT
people are viewing this right now
Ask for More Info
Guaranteed Safe Checkout
The GIGABYTE B760 DS3H DDR4 motherboard is based on the Intel B760 chipset and supports Intel®® processors for the 1700th and 13th generation Socket 12. It has four DDR4 DIMM slots in dual-channel mode for up to 128 GB of memory. The GIGABYTE B760 DS3H DDR4 also features a PCIe 4.0 x16 slot and four PCIe 3.0 x16 slots. In addition, the GIGABYTE B760 DS3H DDR4 has 8-channel sound, a Gigabit LAN interface, four SATA3 ports, two M.2 ports and a number of USB interfaces.
| Type | Motherboard | ||
| EAN | 4719331850746 | ||
| Manufacturer No. | B760 DS3H DDR4 | ||
| Plinth | 1700 | ||
| Maximum CPUs Supported | 1 | ||
| Operating system | Support | Windows 10 ready, Windows 11 ready | |
| Processor | Supported Models | Core i3 12xxx (Alder Lake), Core i3 12xxxT (Alder Lake), Core i3 12xxxF (Alder Lake), Core i3 13xxx (Raptor Lake), Core i3 13xxxF (Raptor Lake), Core i3 13xxxT (Raptor Lake), Core i5 12xxx (Alder Lake), Core i5 12xxxK (Alder Lake), Core i5 12xxxKF (Alder Lake), Core i5 12xxxT (Alder Lake), Core i5 12xxxF (Alder Lake), Core i5 13xxx (Raptor Lake), Core i5 13xxxF (Raptor Lake), Core i5 13xxxT (Raptor Lake), Core i5 13xxxK (Raptor Lake), Core i5 13xxxKF (Raptor Lake), Core i7 12xxx (Alder Lake), Core i7 12xxxK (Alder Lake), Core i7 12xxxKF (Alder Lake), Core i7 12xxxT (Alder Lake), Core i7 12xxxF (Alder Lake), Core i7 13xxx (Raptor Lake), Core i7 13xxxF (Raptor Lake), Core i7 13xxxT (Raptor Lake), Core i7 13xxxK (Raptor Lake), Core i7 13xxxKF (Raptor Lake), Core i9 12xxx (Alder Lake), Core i9 12xxxK (Alder Lake), Core i9 12xxxKF (Alder Lake), Core i9 12xxxT (Alder Lake), Core i9 12xxxF (Alder Lake), Core i9 12xxxKS (Alder Lake), Core i9 13xxx (Raptor Lake), Core i9 13xxxF (Raptor Lake), Core i9 13xxxT (Raptor Lake), Core i9 13xxxK (Raptor Lake), Core i9 13xxxK (Raptor Lake), Core i9 13xxxKF (Raptor Lake), Core i9 13xxxKS (Raptor Lake) | |
| Chipset | Intel® B760 | ||
| Slots | PCIe x16 | 5x (of which: 1x PCIe x16, 4x PCIe x1) | |
| BIOS | 128 Mbit AMI UEFI BIOS | ||
| Form factor | ATX | ||
| Use | PC | ||
| Power supply | ATX12V (24-pin + 8-pin) | ||
| Memory | maximum | 128 GB | |
| Number of sockets | 4x DDR4 | ||
| Supported memory type | SDRAM-DDR4 | ||
| Supported standards | DDR4-5333(O.C.) / 5133(O.C.) / 5000(O.C.) / 4933(O.C.) / 4800(O.C.) / 4700(O.C.) / 4600(O.C.) / 4500(O.C.) / 4400(O.C.) / 4300(O.C.) / 4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3666(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200/ 3000/ 2933/ 2666/ 2400/ 2133 Mhz | ||
| Channels | 2 | ||
| Maximum Memory Ranks | 8 | ||
| Memory controller in CPU | Yes | ||
| Connections (external) | Mouse/Keyboard Combo (PS/2) | 1 | |
| USB-C 3.2 Gen 2×2 (20 Gbps) | 1 | ||
| USB-A 3.2 Gen 2 (10 Gbps) | 1 | ||
| USB-A 2.0 | 4 | ||
| HDMI | 1 | ||
| DisplayPort-Out | 1 | ||
| Microphone | 1 | ||
| Line | 1 | ||
| Line-Out | 1 | ||
| RJ-45 | 1 | ||
| Connections (internal) | SATA | 4 | |
| M.2 | 2 | ||
| RGB LED Header | 2 | ||
| addressable RGB LED Header | 2 | ||
| 4-pole PWM fan | 6 | ||
| SATA Controller | Intel® B760 | ||
| USB Controller | Intel® B760 | ||
| Onboard Graphics | The graphics connectors of the motherboard can only be used when using a CPU with an integrated graphics chip. | ||
| Sound | Realtek Audio CODEC | ||
| LAN | Realtek GbE LAN | ||
| Additional Information | In order to support the latest processor cores, a BIOS update may be required. | ||
| Dimensions | Width: 244 mm x Height: 305 mm | ||
Waranty : Comes with manufactures warranty of 2 years!
TERMS OF SALE
- Please provide payment proof within 24 hours of your order being placed
- A unit can only be reserved once payment has been received, not when an order is placed online
- All sales are final, no refunds will be granted
- Bank transfer payments payment proof has to be provided as soon as order made, as miner prices can change couple times a day.
Shipping :
- Typical dispatch time within 7 working days
- Full customer support before and after purchase
Europe express delivery 1-3 days , economy shipping 3-6 days. US and Asia shipping 2-5 days to deliver to your door.
All items shipped with DHL.
| Weight | 1 kg |
|---|---|
| Dimensions | 30 × 30 × 35 cm |
