Description

CABLE LENGTH
ATX Cable 1x 600mm (m)
EPS Cable 2x 700mm (m)
PCIe Cable 2x 700mm (m), 3x 700mm, 850mm (m)
SATA Cable 4x 550mm, 650mm, 750mm (m)
Four-Pin Peripheral Cable 1x 550mm, 650mm, 750mm (m)
Floppy Adapter 1x Molex to FDD Adapter
AC Power 1x 1500mm (m)
Modular Cable Type Full
Molex to FDD 1x
CONNECTOR QUANTITY
24 Pin ATX 1x
EPS (CPU) 2x 8pin(4+4)
PCIe 8x 8pin(6+2)
SATA 12x
Four-Pin Peripheral 4x
Floppy 1x
POWER SPECS
AC Input 100-240V~, 12-6A, 60/50Hz
Rail +3.3V +5V +12V +5Vsb -12V
Max Output 25A 25A 83.3A 3A 0.5A
130W 1000W 15W 6W
Total 1000W
ADDITIONAL DETAILS
Operating Temperature 0° to 50° C
Japanese Capacitors 100%
ECO Mode Yes
MTBF 100,000 Hours
Net Weight 9 lbs
Size 86mm (H) x 150mm (W) x 150mm (L)
Approvals TUV, CB, CE, FCC, RCM, cTUVus, WEEE, RoHS
Compliance with ErP Lot 3 2014 Requirement
Fan Size / Bearing 135mm Fluid Dynamic Bearing
Product Warranty
This product comes with a 10 year limited warranty with registration.
EVGA offers several warranty solutions for our customers to choose from. Please refer to the suffix of the part number and our Warranty Terms for details.
