Avalon Miner RMA Guide: Video Evidence, Part Replacement and Error Codes

Avalon Miner RMA Guide: Video Evidence, Part Repla...

A faulty Avalon home miner does not always mean a trip back to the factory. Canaan's support team can often ship a replacement power supply or fan directly to you — without you sending the miner anywhere — if your warranty claim contains the right video evidence. This guide walks through the complete RMA process for the Avalon Nano 3S, Avalon Mini 3 and Avalon Q: how to open a claim, what to film, which faults qualify for part-only replacement, and what never to do with serial numbers.

Read this before touching any screws. Every part inside an Avalon miner — the power supply, every fan, the controller, the hashboard — carries its own serial number, and Canaan's warranty system tracks which serial belongs to which machine. If you swap parts between two miners, or install a random replacement part yourself, the serial numbers no longer match and Canaan will refuse the warranty claim. Diagnose first, film the evidence, then wait for instructions.

How to open an Avalon RMA claim

  1. Start with your proof of purchase. Find your Mineshop order confirmation — it contains the order number and purchase date that establish warranty coverage. The standard Canaan warranty period for Avalon home miners is 180 days from delivery.
  2. Email Canaan support directly at avalonsupport@canaan.io. Include: your miner model (Nano 3S, Mini 3 or Q), the miner's serial number, the purchase date and seller, a clear description of the fault, and your shipping address. If you bought from Mineshop, you can also reach our support team and we will help you prepare the claim.
  3. Film the video evidence as described below — this is the step that decides whether you get a fast part replacement or a full RMA.
  4. Wait for Canaan's reply. They will confirm the diagnosis from your video and either dispatch a replacement part with fitting instructions, or issue an RMA number and shipping instructions for the whole unit.
  5. If a full return is needed, Canaan will direct you to the authorised repair centre for your region — in the EU, repair centres are located in Portugal and the Netherlands. Ship only after you have an RMA number; unlabelled parcels cannot be processed.

The video method: get a replacement part without sending your miner back

Canaan's support engineers diagnose remotely from video. A clear, uncut video that shows serial numbers and the fault reproducing can qualify you for a part-only replacement — the fastest outcome, because the part ships to you and your miner never leaves your desk.

Example 1: Nano 3S with a faulty power supply

Symptoms: the Nano 3S will not power on, cycles on and off, or the display stays dark despite a confirmed wall outlet. To film the evidence:

  1. Film the miner's serial number label first — hold the camera close enough that every character is readable.
  2. Film the power supply's serial number label the same way.
  3. Connect the PSU and show the fault reproducing: the miner failing to start, the display staying blank, or the fault behaviour you observed.
  4. If you have a known-working PSU from another same-model miner, swap it in on camera and show the miner booting normally. This side-by-side proof — not-working PSU plus working PSU, both serial numbers visible — is what confirms the PSU is the faulty part.
  5. Send the video link or file to avalonsupport@canaan.io with your claim.

If the diagnosis is confirmed, Canaan typically ships a replacement PSU to you — no miner return needed. The same logic applies to the Avalon Mini 3.

Example 2: Avalon Q with a faulty fan

Symptoms: one fan stops spinning, spins erratically, or the Q reports a fan error on its display or web interface. To film:

  1. Film the miner's serial number and then the serial number on the faulty fan itself — open the service access on camera so the support engineer can see which physical fan has which serial.
  2. Show the faulty fan not spinning (or spinning abnormally) while the other fans run normally.
  3. If the web interface shows a fan error, film the screen showing the error alongside the physical fan.

With this evidence, Canaan can send a replacement fan and step-by-step replacement instructions for the Q — again without a full return. The fan swap on the Avalon Q is designed to be serviceable: unplug the faulty fan's connector, remove the mounting screws, install the new fan, and connect it. Always follow the instructions Canaan sends with the part, and never force a connector.

When you must send the whole miner

Faults inside the sealed assembly — hashboard failures, controller problems, chronic overheating that is not fan- or PSU-related, or errors that persist after a replacement part — normally require the full device to go to the repair centre. Canaan will issue an RMA number and shipping instructions. Pack the miner in its original packaging if you still have it, include the RMA number on the label, and use a tracked service. Repair centres for the EU are in Portugal and the Netherlands, so return shipping is domestic-rate for most customers.

Common faults and error codes on Avalon home miners

The Avalon home series reports faults through the on-device display and the web interface using E-numbered codes. The code customers ask us about most often is E-03: a cooling fan fault — one fan has stopped spinning or is not reporting speed. Here are the faults we see most in Mineshop support, with the outcomes they typically lead to:

What you seeWhat it usually meansLikely outcome
E-03 (fan error)A cooling fan has failed or is not reporting speedVideo evidence with fan SN → replacement fan, no return needed
No power / dead displayPower supply failure (miner itself may be fine)Video with PSU serial → replacement PSU, no return needed
Temperature warningFan degradation, blocked airflow or ambient overheatingClean vents and check placement first; fan may need replacement
Pool / network errorWi-Fi or pool configuration, not a hardware faultConfiguration issue — no RMA needed
Low hashrateThermal throttling, pool variance or a degrading componentReport with screenshots; Canaan will advise
Other E-codesHardware faults — hashboard, controller or power circuitUsually requires full device return to the repair centre

Code meanings reflect Mineshop's repair experience with the Nano 3S, Mini 3 and Q, and Canaan's support guidance. Canaan support confirms the exact meaning of your specific code during the RMA email exchange — always include the code from your display or web interface when you write to avalonsupport@canaan.io.

Never swap parts between miners

This deserves its own section because it is the single most common way customers lose their warranty. Imagine you own two Nano 3S units and one has a dead PSU. The tempting move is to borrow the PSU from the healthy miner to confirm the diagnosis. The problem: the moment you power the faulty miner with a PSU whose serial number belongs to the other machine, Canaan's records show a mismatch. If you then film that video and send it as evidence, the claim can be refused — the support team cannot verify which part is actually faulty when serial numbers have crossed machines.

The safe version: use a clearly labelled test PSU that you state in your email is used only for testing, or ask Canaan's support team first. And never install third-party or salvaged parts inside an in-warranty miner — an unrelated part failure later will not be covered if non-original serials are found inside.

After warranty: parts are available

When the warranty period ends, you are not stuck. Replacement parts and accessories — including power supplies and cooling components for home miners — are available from Mineshop, and our support team can help identify the correct part for your model. Using original, serial-tracked parts keeps your miner serviceable and preserves its resale documentation.

Quick checklist before you email Canaan

  • Miner model and serial number (photo the label)
  • Proof of purchase (order number and date)
  • Fault description: what happens, when it started, what you already tried
  • Video: miner SN → part SN → fault reproducing → (optional) working part test
  • Error code from the display or web interface, if one is shown
  • Your full shipping address and phone number for the courier

Send all of this in one email to avalonsupport@canaan.io, copy the Mineshop support team if you bought from us, and keep the thread until the case is closed. For more on keeping your Avalon healthy in the first place, see our firmware update guide and the Nano 3S vs Mini 3 vs Q comparison for model-specific behaviour.
