HOME MINING · SHA-256 · FLAGSHIP COOLING
NerdQX 8T Home Bitcoin Miner
8 TH/s · 140W · 4× BM1370 · 3-Fan · 6-Pipe Tower Cooler · ≤40 dB
The NerdQX 8T is a high-performance home bitcoin miner that redefines what's possible from a desktop ASIC. Powered by 4× BM1370 ASIC chips, it delivers a powerful hashrate of up to 8 TH/s at just 140W — bringing mining performance comparable to professional equipment to your desk, shelf, or home office.
To ensure the continuous and stable release of 8 TH/s, the NerdQX 8T employs a newly upgraded flagship-level cooling system: a massive 120mm tower heatsink with six pure copper heat pipes and a 3-fan 3D airflow design. The result is efficient, quiet cooling that fundamentally solves the heat dissipation challenges of high hashrate — enabling stable 24/7 operation at ≤40 dB.
4× BM1370 ASIC Chips
Same 7nm chips from the Antminer S21 Pro. Four chips push up to 8 TH/s of SHA-256 hashrate — professional-grade performance from a desktop device.
120mm Tower Heatsink
Massive 120mm heatsink with dense aluminum fins provides a heat dissipation area far exceeding standard coolers — the foundation of the NerdQX's thermal advantage.
6 Pure Copper Heat Pipes
Six high-conductivity pure copper heat pipes rapidly transfer heat from the ASIC chips to the heatsink fins — ensuring instant thermal dissipation under full load.
3-Fan 3D Airflow
Three-fan configuration creates powerful, optimized 3D airflow across the entire unit. Quickly dissipates heat from chips, VRM, and PCB — even during extended 24/7 operation.
⊕
Solo & Pool Mining
Solo mine for the full 3.125 BTC block reward via Public Pool, CKPool, or your own node. Or join any Stratum V1 pool (PPS/PPLNS) for steady daily payouts.
Color LCD & WiFi
Built-in color LCD status screen shows live hashrate, temperature, power, and pool data. 2.4GHz WiFi for wireless plug-and-play setup via browser interface.
The NerdQX 8T's cooling system is engineered from the ground up for sustained high-hashrate operation — not borrowed from standard CPU coolers:
120mm large-size tower heatsink 6× pure copper heat pipes 3-fan 3D airflow design Dedicated VREG heatsink Stable low temps 24/7 ≤40 dB quiet operation
Efficient heat dissipation means lower core temperatures, more stable hashrate, lower noise, and a longer hardware lifespan — making every computation more reliable.
Every hash is an independent chance at the full 3.125 BTC block reward (currently worth over $300,000). At 8 TH/s, the NerdQX 8T delivers roughly 8× better solo mining odds than a single Bitaxe Gamma and ~1.7× better than a standard NerdQaxe++ — while keeping noise below library levels and power draw at just 140W.
| Model |
NerdQX 8T |
| Algorithm |
SHA-256 |
| ASIC Chips |
4 × BM1370 (7nm) |
| Hashrate |
Up to 8 TH/s |
| Power Consumption |
~140W |
| Efficiency |
~17.5 J/TH |
| Heatsink |
120mm tower, 6× copper pipes |
| Cooling |
3-fan 3D airflow + VREG sink |
| Noise Level |
≤40 dB |
| Display |
Color LCD status screen |
| Connectivity |
2.4GHz WiFi |
| Firmware |
AxeOS (open-source) |
| Power Connector |
XT60 |
| Power Supply |
12V / 18A PSU (included) |
| Dimensions |
~21.8 × 11.9 × 14 cm |
| Operating Temp |
0°C – 40°C |
| Mineable Coins |
BTC, BCH, BSV + SHA-256 |
1× NerdQX 8T Miner (assembled & tested)
1× 12V / 18A Power Supply Adapter + AC Cable
1× Desktop Stand
1× Quick-Start Guide
Frequently Asked Questions
What makes the NerdQX 8T different from a standard NerdQaxe++?
Both use 4× BM1370 chips, but the NerdQX 8T is built for higher sustained hashrate. The standard NerdQaxe++ delivers ~4.8 TH/s at stock (up to ~6 TH/s overclocked) with a small low-profile cooler. The NerdQX 8T pushes to 8 TH/s with a flagship 120mm tower heatsink, 6 pure copper heat pipes, 3-fan 3D airflow, and a dedicated VREG heatsink — maintaining stability and low noise at higher frequencies where lesser coolers would throttle.
Is it quiet enough for a bedroom or office?
Yes. Despite the 8 TH/s hashrate, the NerdQX 8T operates at ≤40 dB — comparable to a quiet library. The 3-fan design distributes airflow efficiently at lower RPMs rather than relying on a single high-speed fan. The oversized 120mm tower heatsink provides so much thermal headroom that the fans rarely need to spin up aggressively.
How much electricity does it consume?
At 8 TH/s, the NerdQX 8T draws approximately 140W. At an average electricity rate of $0.20/kWh, monthly costs are approximately $20. The efficiency of ~17.5 J/TH is competitive for a quad-chip miner and the cooling system ensures you sustain that hashrate without thermal throttling.
Why does the cooling system matter so much?
At 8 TH/s, the BM1370 chips generate significantly more heat than at stock 4.8 TH/s. Without adequate cooling, the miner would thermally throttle — reducing hashrate, increasing instability, and shortening chip lifespan. The NerdQX's 120mm tower heatsink with 6 copper heat pipes provides a massive thermal buffer, and the 3-fan system ensures heat is removed from both the chips and the voltage regulators. The result: stable 8 TH/s output 24/7 without throttling.
Do I need technical skills to set it up?
Not at all. Connect the included 12V PSU via the XT60 connector, power on, and connect to the miner's WiFi network from your phone or laptop. Enter your home WiFi credentials and mining pool details through the AxeOS web interface, and mining starts within minutes. No external computer, soldering, or coding required.
Ships worldwide. Typical delivery 5–8 business days via DHL, UPS, or FedEx.
US USA CA Canada EU EU GB UK AU Australia Asia-Pacific Middle East & Africa Latin America
6-month manufacturer warranty. All devices assembled, tested, and verified before shipping.
